OS: Linux embedded personalizzato
CPU & Memoria: Dual Core ARM Cortex A9, 1.0Ghz | Main Memory (1GByte, DDR2 1066Mhz) | NAND Flash 8GByte
CD-Ripping: Sì (tramite lettore/masterizzatore DVD-RW USB | opzionale)
CD-Drive: No (opzionale)
Media supportati: CD, CD-DA, CD-R, CD-RW, DVD-R/RW, CD MQA
CD Metadati testuali: Gracenote (servizio facoltativo a 5Euro per anno)
CD Metadati copertine: Gracenote (servizio facoltativo a 5Euro per anno) | Bing | Google | Amazon | 7Digital | Allcdcovers
Display frontale: 4.6 pollici Full Color TFT LCD (800 X 320 pixels)
Interfacce: "Telecomando, Pulsanti & Jog | Interfaccia Utente su LCD da 4.6" | App MusicX NEO per dispositivi Android e iOS"
Frequenze & CODEC: PCM fino a 32bit/384Khz | DXD 24bit/352.8Khz | DSD64 (2.8224Mhz) | DSD128 (5.6448Mhz) | DSD256 (11.2896Mhz) | MQA
DAC: ESS ES9018K2M, Sabre³² DAC | fino a 32bit/384Khz
Oscillatore: TCXO
Uscite Analogiche: RCA/LR Sbilanciato (Pre-Out) | Gamma Dinamica: -127dB (Max 2Vrms, Stereo) | THD+N: <0.0003% | Volume Fisso/Variabile (regolabile da menu)
Uscite Altoparlanti (casse): SI. Amplificatore Integrato in Classe D da 75 Watt per canale ad 8 Ohm (possono essere collegati anche diffusori a 4 Ohm)
Uscite Cuffia: No
Uscite Digitali: Toslink x 1: 24bit/192Khz | Coassiale x 1 (75 ohm RCA): 24bit/192Khz | USB Audio Out x 1: USB Audio Class 2.0 | Volume Fisso/Variabile (regolabile da App)
Bluetooth SINK (Ricevitore): Sì: Bluetooth aptX 5 | Profili: AVRCP / A2DP | Formato: SBC, AAC, aptX, aptX LL, aptX HD
12V Trigger: No
Ingressi Analogici: No
Phono IN: No
Ingressi Digitali: Toslink x 1: 24bit/192Khz | Coassiale x 1 (75ohm RCA): 24bit/192Khz | HDMI ARC x 1: 24bit/192Khz
USB Audio Input: Connettore USB tipo B
(USB DAC): Ingresso USB Audio Class 2.0 | Supporta PCM 384Khz/32Bit, DSD Native 256, MQA
Sintonizzatore DAB/DAB+: DAB/DAB+, Full Band III frequency range (174~240Mhz), MP2 audio da 32 a 384Kbps, AAC+(HE AAC v2 fedele a ETSI TS 102 653)
Sintonizzatore FM: FM Radio RDS (FM 87.5~108Mhz) | Impedenza Antenna FM: 75ohm sbilanciato
Connettività: 3.0 USB Host Port (5V/1A) x 2 | 2.0 USB Host Port (5V/1A) x 1 | Giga Fast Ethernet LAN (10/100/1000Mbps) | Opzionale: 801.11b/g/n WiFi USB Dongle | Opzionale: Trasmettitore Bluetooth aptX 5.0
Storage supportato: Esterno USB | Esterno NAS | File system supportati: NTFS o Linux
Sistema RAID: No
Riproduzione MQA: Sì, nativa (full-unfold)
Codec Audio & Formati: DSD (64/128/256) DFF/DSF | MQA (inclusi i CD MQA) | PCM fino a 32bit/384Khz | APE/CUE | DXD, FLAC, WAV, ALAC, AIFF, AIF, AAC, M4A, MP3, WMA, Ogg, PCM, Playlist (M3U, PLS)
Protocolli di Rete: DLNA (UPnP) Server/Client/Media Renderer | Shareplay (Airplay) | Samba Server/Client | FTP Server | Web Server
Radio Internet & Podcast: Internet Radio con Airable | Podcast con Airable
Funzione di registrazione: Sì (per Radio Internet, Radio FM, DAB+) | Frequenza 48/96/192Khz, 24bit
Funzione di masterizzazione CD: Sì, masterizzazione su Compact Disc Audio CD-R | con masterizzatore DVD-RW USB (opzionale)
Riproduzione Streaming da NAS: Sì, fino a PCM 32bit/384kHz e DSD256 (11.2896Mhz)
Roon Ready: Sì
Multi-Room (Group Play): Sì
Servizi di Musica Online: Spotify Connect | TIDAL (anche TIDAL HIFI e TIDAL MASTER MQA) | Deezer | Qobuz (Anche Qobuz Studio fino a 24bit/192kHz) | Napster | HighresAudio | Amazon Music
Dissipazione: Completamente passiva | Nessuna ventola | Silenziosità assoluta
Alimentazione: Trasformatore 36W SMPS integrato (per la CPU e sezione digitale) | Trasformatore Lineare (per la sezione analogica DAC) | AC220V-240V, 50/60Hz
Dimensioni e Peso: Chassis: frontale 10mm di spessore in alluminio. Manopole in alluminio con lavorazione con sistemi CNC. Corpo in metallo | Dimensioni: 44x26x6.1 cm (LxPxA) senza piedini | Peso: 5 Kg
Description
Product Details
About Cocktail Audio
Cocktail Audio, music servers and network players for liquid music
Cocktail Audio is proof that the HiFi world is evolving, and that for this companies need to be ready. The brand in question develops its offerings around the proposition of music servers, network players, DACs and accessories designed specifically for liquid music.
Hearing one's favorite songs via streaming has now become the norm for many casual listeners. Web streaming, often looked upon with suspicion by enthusiasts, however, can also be suitable for audiophiles, provided you have the right tools. Provided, therefore, that you have a device Cocktail Audio.
X45, X14 and more: the ideal solutions for high-fidelity streaming
The Cocktail Audio range includes music servers, network players and DACs. Within these categories are highly successful devices that are particularly popular with the public. Among them is certainly Cocktail Audio X45, a music server with CD-ripping function and native support for DSD and MQA formats. Another very interesting solution is the X14 music server, a compact Hi-Fi system capable of handling audio streams up to 24bit/192kHz.
There are many other interesting products, designed especially for different needs. From the casual listener who wants a complete streaming option, to the audiophile who wants to launch himself into the world of liquid music while being sure to find a serious interlocutor with whom to interface.
Between DACs and receivers, a catalog of innovative devices
It is increasingly difficult to distinguish the boundaries of the audio world, both when it comes to genres and listening media. Liquid music, that which is untied from any physical instrument, is a clear consequence of the direction taken by the market. Music that can be listened to anywhere, in any way, to be enjoyed as quickly as sipping a drink. A real Cocktail Audio, then, as the name of the company itself suggests.
A company that is up against no small feat of offering audiophile products in an area, streaming, that has always been somewhat opposed by hardcore fans. Yet, thanks to CocktailAudio's music servers and network players, it really is possible to have a very high-quality experience even without the aid of physical media. With no more reading errors, no more jitter, here is where listening to your favorite songs immediately becomes easier and more satisfying.
Buy CocktailAudio players at HiFi Prestige
The HiFi Prestige store has the enormous pleasure of hosting Cocktail Audio brand products. Browse the pages of our shop to discover all the offers on music servers, network players, DACs and various accessories (such as remote controls and Wi-Fi adapters). Essential tools for experiencing to the fullest all that liquid music has to offer.
For each device you will find high-definition images, and a description of the most interesting technical features. Purchasing is also facilitated by advantageous prices and frequent promotions. You can even choose deferred payment solutions: the installment amount is clearly marked in the product sheet of each model.
